ATEN TECHNOLOGIES · IM00HQ99

ATEN CS1184H4, 4-Port USB HDMI KVM Switch, 4K Ultra HD 3840×2160, PSD PP v4.0 Secure, 5W

$643$6491%

ATEN CS1184H4, 3840 x 2160 pixels, 4K Ultra HD, 5 W, Black

  • NIAP Common Criteria Compliant
  • Compliant with PSD PP v4.0 (Protection Profile for Peripheral Sharing Device, Version 4.0) security requirements
  • Multi-Layered Security
  • Always-on chassis intrusion detection – renders the ATEN PSD PP v4.0 Secure KVM Switch series inoperable when physical tampering is detected
  • Tamper-evident labels – provides visual indication of any attempt to access the ATEN PSD PP v4.0 Secure KVM Switch’s internal components
  • Non-reprogrammable firmware – prevents reprogramming the ATEN PSD PP v4.0 Secure KVM Switch’s firmware
In stock · 9 units · Ships tomorrow
Shipping calculated at checkout
30-day returns · no questions asked
Sourced via Ingram Micro · ships from US distribution

About this product

ATEN PSD PP v4.0 Secure KVM Switch CS1184H4 is specifically designed to meet the stringent security requirement of secure defense and intelligence installations. ATEN PSD PP v4.0 Secure KVM Switch CS1184H4 is compliant with PSD PP v4.0 (Protection Profile for Peripheral Sharing Device, Version 4.0) standard certified by the National Information Assurance Partnership (NIAP).

ATEN PSD PP v4.0 Secure KVM Switch CS1184H4 provides isolation between computer sources and peripherals while sharing a single keyboard, mouse, monitor, and speaker set between connected computers of various security classifications. Compliance with PSD PP v4.0 ensures peripheral sharing capabilities provide maximum user data security when switching port focus, preventing unauthorized data flows or leakage between connected sources. Key protections include isolation and unidirectional data flow, restricted peripheral connectivity and filtering, user data protection, configurable device filtration and management, strict audio filtration, and always-on tamper-proof design, keeping sensitive assets isolated and providing advanced security and a user friendly design for instantly secure deployment.

To enhance security, ATEN PSD PP v4.0 Secure KVM Switch CS1184H4 only offers manual switching methods including front panel pushbuttons and Remote Port Selector (RPS) 1. With multi – layered security, ATEN PSD PP v4.0 Secure KVM Switch CS1184H4 ensures high-level desktop security and data safekeeping for applications such as government and military agencies, healthcare providers, banking and finance institutions, and other organizations that often handle sensitive or confidential data on separate networks.

Note:
1. The Remote Port Selector is not supplied in the package and requires a separate purchase.
Download datasheet (PDF)Manufacturer product page

Specifications

Connectivity

KVM Ports
4

Power

Input Voltage Range
100-240 V
Power Consumption
5 W

Security

Certification
PSD PP v4.0

Video

Maximum Resolution
3840 x 2160 pixels
Video Port Type
HDMI
Video Bandwidth
60 Hz

Product details

Brand
ATEN TECHNOLOGIES
Vendor
ATEN TECHNOLOGIES
Ingram Part Number
00HQ99
UPC
0672792013898
MSRP
$649
Stock
9 units
