Club · IM8TP436

Club DisplayPort 1.4 to HDMI Dual Monitor Hub, 4K60Hz, MST, 2× HDMI

CLUB3D Multi Stream Transport (MST) Hub DisplayPort 1.4 to HDMI Dual Monitor 4K60Hz M/F, DisplayPort, 2x HDMI, Meets ROHS, FCC, and CE EMI requirements, 5 g, 28 g, 8473 3020

Features:
Compliant with: DisplayPort™ v1.4, DisplayPort™ v1.2, VESA DDM Standard, HDMI™ 4K60Hz
Supports HDCP 1.4 and HDCP 2.2 Content protection
Supports main link rates of 8.1Gbps (HBR3),5.4Gbps (HBR2), 2.7Gbps (HBR) and (1.62Gbps RBR) from source
Supports up to Two HDMI™ 4K60Hz ports
Supported output resolutions :

Only 2 left · order soon

◇ Shipping calculated at checkout

↩ 30-day returns · no questions asked

⊡ Sourced via Ingram Micro · ships from US distribution

About this product

The Club 3D CSV-7200H Multi Stream Transport(MST)Hub DisplayPort™ 1.4 to Dual HDMI 4K60Hz is an integrated solution that allow you to enjoy displaying content onto two different displays simultaneously under MST mode. The Two screens can accommodate displaying same contents in parallel or by simply extending the existing screen, giving a panoramic view of the content which maximizes the user’s visual experience. With its multi-display capabilities, this hub can serve as a convenient and hassle-free portable, alternative solution to the conventional docking station. It’s the perfect solution for host devices which feature DP1.2 /1.4 graphic cards for gaming and commercial applications.

Download datasheet (PDF)Manufacturer product page
